S.T.E. CONTRACTOR

DEMENSIONS: 8’ to 18’ long 102” wide.

HEADBOARD: 10ga w/ top reinforced structural tubing, window opening and cab shield to match cab.

SIDES: 10ga Std. height 15” (optional), drop down w/greaseable heavy duty hinges, structural tubing top rail, durable 1” latching, 6” board pockets, 1/4” corner posts,

4” x 1-1/2” side floor support.

TAILGATE: 12ga Std. height 24” (optional), lever action drop (air if applicable).

UNDERSTRUCTURE: 6” X 8.2 lbs./ft. structural I beam cross member-less type.

FLOOR: 7ga grade 50 (AR400 optional)

REAR APRON: 1/4” material including light provisions

LIGHTS: LED 3 per side includes wire harness & backup lights, rubber mounted clearance lights in corner posts…..unlimited contractor opt. per customer requests.
